Product
MAXX SERIES D²
New Product
Product
MAXX SERIES D²
The search for an audio solution that saves space, energy, and valuable time on site is over. With the Innosonix D² Maxx Series, never have to compromise on your creativity.
The most powerful offering of Innosonix multi-channel amplifiers, D² provides up to 280 watts to deliver incredible sound from one compact platform. And thanks to the Innosonix DSP processing, there’s no need for external loudspeaker processors. The D2 range is supplied with DANTE, AES3 and MADI connectivity as standard.
MAXX SERIES D²
Product Information
2U – 16 CHANNELS 280W 4Ω
The MA16/D² in common with all MAXX Series amplifiers, is supplied with DANTE, AES3 and MADI connectivity as standard.
Each channel also has comprehensive FPGA-based DSP with Limiting, 32 x IIR EQ filters, FIR filters, Time-Alignment Delay and Loudspeaker Preset Recall.
Key Facts
For more in-depth information on this device scroll down to the Datasheet
Output per Channel
280W @ 4Ω, 140W @ 8Ω and 500W @ 8Ω Bridge Mode
Max Output Voltage
52V Peak and Bridged channels 104V Peak
Channel Count
16 Channels
2U – 24 CHANNELS 280W 4Ω
The MA24/D² in common with all MAXX Series amplifiers, is supplied with DANTE, AES3 and MADI connectivity as standard.
Each channel also has comprehensive FPGA-based DSP with Limiting, 32 x IIR EQ filters, FIR filters, Time-Alignment Delay and Loudspeaker Preset Recall.
Key Facts
For more in-depth information on this device scroll down to the Datasheet
Output per Channel
280W @ 4Ω, 140W @ 8Ω and 500W @ 8Ω Bridge Mode
Max Output Voltage
52V Peak and Bridged channels 104V Peak
Channel Count
24 Channels
2U – 32 CHANNELS 280W 4Ω
The MA32/D² in common with all MAXX Series amplifiers, is supplied with DANTE, AES3 and MADI connectivity as standard.
Each channel also has comprehensive FPGA-based DSP with Limiting, 32 x IIR EQ filters, FIR filters, Time-Alignment Delay and Loudspeaker Preset Recall.
Key Facts
For more in-depth information on this device scroll down to the Datasheet
Output per Channel
280W @ 4Ω, 140W @ 8Ω and 500W @ 8Ω Bridge Mode
Max Output Voltage
52V Peak and Bridged channels 104V Peak
Channel Count
32 Channels
Maxx Remote and Maxx Control streamline your workflow, reducing the need for excess gear and allowing for cost-effective installations.
- User Manual Manual
- Spec Sheet Datasheet
- Certificates EU Declaration of Conformity
- Certificates Certificate of Compliance
- MA16/D² - 2U - 16 CHANNELS 280W 4Ω
- MA24/D² - 2U - 24 CHANNELS 280W 4Ω
- MA32/D² - 2U - 32 CHANNELS 280W 4Ω
Disclaimer: Innosonix operates a policy of continuous development. Apex reserves the right to make changes and improvements to any of the products described on this website without prior notice. Specifications are subject to change without notice. Please refer to the manufacturer’s web page for the most up-to-date specifications and product details www.innosonix.de.
For more information or support, visit: innosonix.de/downloads
A.C. Americas® distributes Innosonix products in the USA only.
