Features:

• Four powerful LED HALO cells with colour temperature shift on dimming for true tungsten emulation
• Individual cell control for effects with sizing and spacing matching traditional linear blinders
• IP65 housing for the most demanding environments with a virtually limitless ‘building block’ rigging system

LIGHT SOURCE

• Source: 3000K White COB 4x72W + Amber 16x3W
• CT: 3000K
• CRI: >92
• Luminous flux: (24°) 10529 lm, (40°) 13837lm
• Lux: (24°) 6330lux @3m
• Lux: (40°) 3364lux @3m
• Source life expectancy: >50.000 h

OPTICS

• Beam angle: (inc) 24° – (opt) 40°
• Field angle: 42°
• Pixel pitch: 150mm / 5.91”
• Lens diameter: 100mm / 3.94”
• Lens type: dichroic parabolic reflector in combination with HD fresnel lens
• Additional optics: 40°(opt), 32° without magnetic lens
• Other: Magnetic replacement of front lens

COLOUR SYSTEM

• Colour mixing: tungsten 3000 + amber shift
• CTC: amber shift activation by DMX

DYNAMIC EFFECTS

• Pixel patterns: pre-programmed dynamic and static patterns
• FX generator: adjustable foreground/background colour, index, speed, direction
• Static colour mode: selection of static colour
• Manual colour mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment
• Special features: Amber shifting for halogen DWE emulation

BODY

• Hardware on-board: on board mechanics for modular assembly of multiple fixtures
• Body: sturdy die-cast aluminium body conceived for long-time durability
• Body colour: black

CONTROL

• Protocols: DMX512, RDM
• DMX channels: HALO 1/4ch – STD 2/4/7ch – EXT 6/8/10channel
• Pixel control: pixel2pixel control
• RDM: RDM ready for fixture remote monitor and settings
• Display: black OLED touch display
• Firmware upgrade: yes, via USB-DMX interface (UPBOX1) not included
• Master/Slave: for synchronized operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0~100% electronic dimmer
• Dimmer curves: 4 different dimming curves available
• Strobe / shutter: 1-28 Hz, electronic
• Battery backup: battery backup for user operation without connecting to the main power
• Operating temperature: -10° ~ +45°
• Flicker: flicker free operation

ELECTRICAL

• Power supply: 100-240V – 50/60Hz
• Power consumption (at 230V): 331W
• Power consumption (at 120V): 341W
• Output (at 230V): 11 units on a single power line
• Output (at 120V): 6 units on a single power line

PHYSICAL

• Cooling: natural cooling of the peculiar chassis and to absence of fans
• Suspension and fixing: hanging bracket suitable for safe hanging and positioning
• Signal connection: IP DMX 5p IN/OUT, IP Art-Net Neutrik IN/OUT
• Power connection: IN Neutrik TRUECON
• IP rating: 65 for temporary outdoor application, not for fixed installation
• Dimensions (WxHxD): 24.37”x6.57”x10.43” / 619x167x265mm
• Weight: 17.64lbs / 8kg
